Description:
CP3 is the Central Processor for the SeaCom 2100 and SeaCom 19'' systems.
The CP3 card is a 64-bit quad-core ARM Cortex-A72 processor running Linux operating system.
The purpose of the CP3 board is to execute the CP software, and to hold the configuration file which stores call numbers, privilege settings etc.
The CP3 board is located anywhere in the board 19’’ magazine, but will typically be inserted just beside the PSU2.
The CP3 has its operating system stored in a write protected partition of the SD card, meaning that it is not possible to destroy the operating system, and if tried to, a reboot will restore to the factory OS.
Specifications:
- 64-bit quad-core ARM Cortex-A72 processor
- 4Gb RAM
- 32Gb SD card disk
- 10/100 Mbit Ethernet
- 4xUSB Serial port
- Twister Linux OS
- Power 24V DC 1W
- DHCP server
